Happy World Quality Day 2018!

Each year, the second Thursday of November day is set aside to reflect on the way quality management can contribute to our work and our lives. Led by the Chartered Quality Institute (CQI) in the United Kingdom, World Quality Day provides a forum to reflect on how we implement more effective processes and systems that positively impact KPIs and business results — and celebrate outcomes and new insights.

This year’s theme is “Quality: A Question of Trust”.

We usually think of quality as an operations function. The quality system (whether we have quality management software implemented or not) helps us keep track of the health and effectiveness of our manufacturing, production, or service processes. Often, we do this to obtain ISO 9001:2015 certification, or achieve outcomes that are essential to how the public perceives us, like reducing scrap, rework, and customer complaints.

But the quality system encompasses all the ways we organize our business — ensuring that people, processes, software, and machines are aligned to meet strategic and operational goals. For example, QMS validation (which is a critical for quality management in the pharmaceutical industry), helps ensure that production equipment is continuously qualified to meet performance standards, and trust is not broken. Intelex partner Glemser Technologies explains in more detail in The Definitive Guide to Validating Your QMS in the Cloud. This extends to managing supplier relationships — building trust to cultivate rich partnerships in the business ecosystem out of agreements to work together.

This also extends to building and cultivating trust-based relationships with our colleagues, partners, and customers…

Read more about how Integrated Management Systems and Industry 4.0/ Quality 4.0 are part of this dynamic: https://community.intelex.com/explore/posts/world-quality-day-2018-question-trust

Quality 4.0: Reveal Hidden Insights with Data Sci & Machine Learning (Webinar)

Quality Digest

What’s Quality 4.0, why is it important, and how can you use it to gain competitive advantage? Did you know you can benefit from Quality 4.0 even if you’re not a manufacturing organization? That’s right. I’ll tell you more next week.

Sign up for my 50-minute webinar at 2pm ET on Tuesday, October 16, 2018 — hosted by Dirk Dusharme and Mike Richman at Quality Digest. This won’t be your traditional “futures” talk to let you know about all of the exciting technology on the horizon… I’ve actually been doing and teaching data science, and applying machine learning to practical problems in quality improvement, for over a decade.

Come to this webinar if:

  1. You have a LOT of data and you don’t know where to begin
  2. You’re kind of behind… you still use paper and Excel and you’re hoping you don’t miss the opportunities here
  3. You’re a data scientist and you want to find out about quality and process improvement
  4. You’re a quality professional and you want to find out more about data science
  5. You’re a quality engineer and you want some professional preparation for what’s on the horizon
  6. You want to be sure you get on our Quality 4.0 mailing list to receive valuable information assets for the next couple years to help you identify and capture opportunities

Register Here! See you on Tuesday. If you can’t make it, we’ll also be at the ASQ Quality 4.0 Summit in Dallas next month sharing more information about the convergence of quality and Big Data.

Happy 10th Birthday!

10 years ago today, this blog published its first post: “How Do I Do a Lean Six Sigma (LSS) Project?” Looking back, it seems like a pretty simple place to have started. I didn’t know whether it would even be useful to anyone, but I was committed to making my personal PDSA cycles high-impact: I was going to export things I learned, or things I found valuable. (As it turns out, many people did appreciate the early posts even though it would take a few years for that to become evident!)

Since then, hundreds more have followed to help people understand more about quality and process improvement in theory and in practice. I started writing because I was in the middle of my PhD dissertation in the Quality Systems program at Indiana State, and I was discovering so many interesting nuggets of information that I wanted to share those with the world – particularly practitioners, who might not have lots of time (or even interest) in sifting through the research. In addition, I was using data science (and some machine learning, although at the time, it was much more difficult to implement) to explore quality-related problems, and could see the earliest signs that this new paradigm for problem solving might help fuel data-driven decision making in the workplace… if only we could make the advanced techniques easy for people in busy jobs to use and apply.

We’re not there yet, but as ASQ and other organizations recognize Quality 4.0 as a focus area, we’re much closer. As a result, I’ve made it my mission to help bring insights from research to practitioners, to make these new innovations real. If you are developing or demonstrating any new innovative techniques that relate to making people, processes, or products better, easier, faster, or less expensive — or reducing risks and building individual and organizational capabilities — let me know!

I’ve also learned a lot in the past decade, most of which I’ve spent helping undergraduate students develop and refine their data-driven decision making skills, and more recently at Intelex (provider of integrated environment, health & safety, and quality management EHSQ software to enterprises and smaller organizations). Here are some of the big lessons:

  1. People are complex. They have multidimensional lives, and work should support and enrich those lives. Any organization that cares about performance — internally and in the market — should examine how it can create complete and meaningful experiences. This applies not only to customers, but to employees and partners and suppliers. It also applies to anyone an organization has the power and potential to impact, no matter how small.
  2. Everybody wants to do a good job (and be recognized for it). How can we create environments where each person is empowered to contribute in all the areas where they have talent and interest? How can these same environments be designed with empathy as a core capability?
  3. Your data are your most valuable assets. It sounds trite, but data is becoming as valuable as warehouses, inventory, and equipment. I was involved in a project a few years ago where we digitized data that had been collected for three years — and by analyzing it, we uncovered improvement opportunities that when implemented, saved thousands of dollars a week. We would not have been able to do that if the data had remained scratched in pencil on thousands of sheets of well-worn legal paper.
  4. Nothing beats domain expertise (especially where data science is concerned). I’ve analyzed terabytes of data over the past decade, and in many cases, the secrets are subtle. Any time you’re using data to make decisions, be sure to engage the people with practical, on-the-ground experience in the area you’re studying.
  5. Self-awareness must be cultivated. The older you get, and the more experience you gain, the more you know what you don’t know. Many of my junior colleagues (and yours) haven’t reached this point yet, and will need some help from senior colleagues to gain this awareness. At the same time, those of you who are senior have valuable lessons to learn from your junior colleagues, too! Quality improvement is grounded in personal and organizational learning, and processes should help people help each other uncover blind spots and work through them — without fear.



Most of all, I discovered that what really matters is learning. We can spend time supporting human and organizational performance, developing and refining processes that have quality baked in, and making sure that products meet all their specifications. But what’s going on under the surface is more profound: people are learning about themselves, they are learning about how to transform inputs into outputs in a way that adds value, and they are learning about each other and their environment. Our processes just encapsulate that organizational knowledge that we develop as we learn.

Writing a Great Article Review

We’re teaching a class on blockchain and cryptocurrencies this semester, and since the field is so new and changing rapidly, we’ve asked our students to make finding and reviewing articles part of their learning practice this semester. This is a particularly challenging topic for this task because there’s so much hype, marketing, and fluff around these topics. We want to slice through that, and improve the signal-to-noise for people new to learning about blockchain and cryptocurrencies. Here are some tips I just prepared for our students — they may be helpful to anyone writing article reviews, especially for technology-related areas.


0 – Type of Source. Reviews or articles from from arXiv, Google Scholar were strong; reviews from Coindesk, CNN were weak; reviews from WSJ and Hacker Noon went both ways. Here are two submissions that were publishable with only minor edits:

1 – Spelling & Grammar. Most of you are college seniors, and the few who aren’t… are juniors. Please use complete sentences that make sense, with words that are spelled correctly! If this is hard for you, remember that every one of you has spell check. One way to remember this is to draft your posts in Word, and then perform spell check before you copy and paste what you wrote into WordPress.

1 – Your job is to create the TL;DR. What’s the essential substance of the source you’re reviewing? What are the main lessons or findings? If you were taking notes for an exam, what elements would you capture? (Using this perspective, commentary about how good or bad you think the article was, or what it didn’t cover well, would not help you on an exam.)

2 – Choose solid source material — primary sources, e.g. research papers, if possible. If the article is less than ~400-500 words, it’s probably not detailed enough to write a 250-300 word summary/analysis. Your job in this class is to break down complex topics & help people understand them. If your article is short and already very easy to understand, there’s nothing for you to do.

3 – Avoid “weasel words” (phrases or sentences that sound like marketing or clickbait but actually say nothing) and words/sentences that sound like you’re writing a Yelp or Amazon review rather than a critical academic review. Here are a couple weaselly examples drawn from this week’s draft posts (see if you can spot what’s wrong):

  • It is clear how beneficial blockchain can be to smaller businesses.
  • Blockchain has the potential to change the world.
  • Each other the topics covered in the article deserve their own piece and could be augmented upon greatly.
  • There is a degree of uncertainty that comes with an emerging technology.
  • Blockchain can bring them into the 21st century to compete with larger corporations.
  • Many people are scared of the changes, and governments will seek to regulate it.

4 – Answer the “so what” question. Why is this topic interesting or compelling?

5 – Choose information-rich tags. For example, in our class, don’t include blockchain as a tag… pretty much everything we do will be related to blockchain, and everyone will tend to use it, so there won’t be much information contained in the tag.

Where Do Z-Score Tables Come From? (+ how to make them in R)

z-score-table-iconEvery student learns how to look up areas under the normal curve using Z-Score tables in their first statistics class. But what is less commonly covered, especially in courses where calculus is not a prerequisite, is where those Z-Score tables come from: by evaluating the integral of the equation for the bell-shaped normal curve, usually from -Inf to the z-score of interest. This is the same thing that the R command pnorm does when you provide it with a z-score. Here is the slide presentation I put together to explain the use and origin of the Z-Score table, and how it relates to pnorm and qnorm (the command that lets you input an area to find the z-score at which the area to the left is swiped out). It’s free to use under Creative Commons, and is part of the course materials that is available for use with this 2015 book.

One of the fun things I did was to make my own z-score table in R. I don’t know why anyone would WANT to do this — they are easy to find in books, and online, and if you know how to use pnorm and qnorm, you don’t need one at all. But, you can, and here’s how.

First, let’s create a z-score table just with left-tail areas. Using symmetry, we can also use this to get any areas in the right tail, because the area to the left of any -z is the same as any area to the right of any +z. Even though the z-score table contains areas in its cells, our first step is to create a table just of the z-scores that correspond to each cell:

c0 <- seq(-3.4,0,.1)
c1 <- seq(-3.41,0,.1)
c2 <- seq(-3.42,0,.1)
c3 <- seq(-3.43,0,.1)
c4 <- seq(-3.44,0,.1)
c5 <- seq(-3.45,0,.1)
c6 <- seq(-3.46,0,.1)
c7 <- seq(-3.47,0,.1)
c8 <- seq(-3.48,0,.1)
c9 <- seq(-3.49,0,.1)
z <- cbind(c0,c1,c2,c3,c4,c5,c6,c7,c8,c9)
z

 c0 c1 c2 c3 c4 c5 c6 c7 c8 c9
 [1,] -3.4 -3.41 -3.42 -3.43 -3.44 -3.45 -3.46 -3.47 -3.48 -3.49
 [2,] -3.3 -3.31 -3.32 -3.33 -3.34 -3.35 -3.36 -3.37 -3.38 -3.39
 [3,] -3.2 -3.21 -3.22 -3.23 -3.24 -3.25 -3.26 -3.27 -3.28 -3.29
 [4,] -3.1 -3.11 -3.12 -3.13 -3.14 -3.15 -3.16 -3.17 -3.18 -3.19
 [5,] -3.0 -3.01 -3.02 -3.03 -3.04 -3.05 -3.06 -3.07 -3.08 -3.09
 [6,] -2.9 -2.91 -2.92 -2.93 -2.94 -2.95 -2.96 -2.97 -2.98 -2.99
 [7,] -2.8 -2.81 -2.82 -2.83 -2.84 -2.85 -2.86 -2.87 -2.88 -2.89
 [8,] -2.7 -2.71 -2.72 -2.73 -2.74 -2.75 -2.76 -2.77 -2.78 -2.79
 [9,] -2.6 -2.61 -2.62 -2.63 -2.64 -2.65 -2.66 -2.67 -2.68 -2.69
[10,] -2.5 -2.51 -2.52 -2.53 -2.54 -2.55 -2.56 -2.57 -2.58 -2.59
[11,] -2.4 -2.41 -2.42 -2.43 -2.44 -2.45 -2.46 -2.47 -2.48 -2.49
[12,] -2.3 -2.31 -2.32 -2.33 -2.34 -2.35 -2.36 -2.37 -2.38 -2.39
[13,] -2.2 -2.21 -2.22 -2.23 -2.24 -2.25 -2.26 -2.27 -2.28 -2.29
[14,] -2.1 -2.11 -2.12 -2.13 -2.14 -2.15 -2.16 -2.17 -2.18 -2.19
[15,] -2.0 -2.01 -2.02 -2.03 -2.04 -2.05 -2.06 -2.07 -2.08 -2.09
[16,] -1.9 -1.91 -1.92 -1.93 -1.94 -1.95 -1.96 -1.97 -1.98 -1.99
[17,] -1.8 -1.81 -1.82 -1.83 -1.84 -1.85 -1.86 -1.87 -1.88 -1.89
[18,] -1.7 -1.71 -1.72 -1.73 -1.74 -1.75 -1.76 -1.77 -1.78 -1.79
[19,] -1.6 -1.61 -1.62 -1.63 -1.64 -1.65 -1.66 -1.67 -1.68 -1.69
[20,] -1.5 -1.51 -1.52 -1.53 -1.54 -1.55 -1.56 -1.57 -1.58 -1.59
[21,] -1.4 -1.41 -1.42 -1.43 -1.44 -1.45 -1.46 -1.47 -1.48 -1.49
[22,] -1.3 -1.31 -1.32 -1.33 -1.34 -1.35 -1.36 -1.37 -1.38 -1.39
[23,] -1.2 -1.21 -1.22 -1.23 -1.24 -1.25 -1.26 -1.27 -1.28 -1.29
[24,] -1.1 -1.11 -1.12 -1.13 -1.14 -1.15 -1.16 -1.17 -1.18 -1.19
[25,] -1.0 -1.01 -1.02 -1.03 -1.04 -1.05 -1.06 -1.07 -1.08 -1.09
[26,] -0.9 -0.91 -0.92 -0.93 -0.94 -0.95 -0.96 -0.97 -0.98 -0.99
[27,] -0.8 -0.81 -0.82 -0.83 -0.84 -0.85 -0.86 -0.87 -0.88 -0.89
[28,] -0.7 -0.71 -0.72 -0.73 -0.74 -0.75 -0.76 -0.77 -0.78 -0.79
[29,] -0.6 -0.61 -0.62 -0.63 -0.64 -0.65 -0.66 -0.67 -0.68 -0.69
[30,] -0.5 -0.51 -0.52 -0.53 -0.54 -0.55 -0.56 -0.57 -0.58 -0.59
[31,] -0.4 -0.41 -0.42 -0.43 -0.44 -0.45 -0.46 -0.47 -0.48 -0.49
[32,] -0.3 -0.31 -0.32 -0.33 -0.34 -0.35 -0.36 -0.37 -0.38 -0.39
[33,] -0.2 -0.21 -0.22 -0.23 -0.24 -0.25 -0.26 -0.27 -0.28 -0.29
[34,] -0.1 -0.11 -0.12 -0.13 -0.14 -0.15 -0.16 -0.17 -0.18 -0.19
[35,] 0.0 -0.01 -0.02 -0.03 -0.04 -0.05 -0.06 -0.07 -0.08 -0.09

Now that we have slots for all the z-scores, we can use pnorm to transform all those values into the areas that are swiped out to the left of that z-score. This part is easy, and only takes one line. The remaining three lines format and display the z-score table:

zscore.df <- round(pnorm(z),4)
row.names(zscore.df) <- sprintf("%.2f", c0)
colnames(zscore.df) <- seq(0,0.09,0.01)
zscore.df

 0 0.01 0.02 0.03 0.04 0.05 0.06 0.07 0.08 0.09
-3.40 0.0003 0.0003 0.0003 0.0003 0.0003 0.0003 0.0003 0.0003 0.0003 0.0002
-3.30 0.0005 0.0005 0.0005 0.0004 0.0004 0.0004 0.0004 0.0004 0.0004 0.0003
-3.20 0.0007 0.0007 0.0006 0.0006 0.0006 0.0006 0.0006 0.0005 0.0005 0.0005
-3.10 0.0010 0.0009 0.0009 0.0009 0.0008 0.0008 0.0008 0.0008 0.0007 0.0007
-3.00 0.0013 0.0013 0.0013 0.0012 0.0012 0.0011 0.0011 0.0011 0.0010 0.0010
-2.90 0.0019 0.0018 0.0018 0.0017 0.0016 0.0016 0.0015 0.0015 0.0014 0.0014
-2.80 0.0026 0.0025 0.0024 0.0023 0.0023 0.0022 0.0021 0.0021 0.0020 0.0019
-2.70 0.0035 0.0034 0.0033 0.0032 0.0031 0.0030 0.0029 0.0028 0.0027 0.0026
-2.60 0.0047 0.0045 0.0044 0.0043 0.0041 0.0040 0.0039 0.0038 0.0037 0.0036
-2.50 0.0062 0.0060 0.0059 0.0057 0.0055 0.0054 0.0052 0.0051 0.0049 0.0048
-2.40 0.0082 0.0080 0.0078 0.0075 0.0073 0.0071 0.0069 0.0068 0.0066 0.0064
-2.30 0.0107 0.0104 0.0102 0.0099 0.0096 0.0094 0.0091 0.0089 0.0087 0.0084
-2.20 0.0139 0.0136 0.0132 0.0129 0.0125 0.0122 0.0119 0.0116 0.0113 0.0110
-2.10 0.0179 0.0174 0.0170 0.0166 0.0162 0.0158 0.0154 0.0150 0.0146 0.0143
-2.00 0.0228 0.0222 0.0217 0.0212 0.0207 0.0202 0.0197 0.0192 0.0188 0.0183
-1.90 0.0287 0.0281 0.0274 0.0268 0.0262 0.0256 0.0250 0.0244 0.0239 0.0233
-1.80 0.0359 0.0351 0.0344 0.0336 0.0329 0.0322 0.0314 0.0307 0.0301 0.0294
-1.70 0.0446 0.0436 0.0427 0.0418 0.0409 0.0401 0.0392 0.0384 0.0375 0.0367
-1.60 0.0548 0.0537 0.0526 0.0516 0.0505 0.0495 0.0485 0.0475 0.0465 0.0455
-1.50 0.0668 0.0655 0.0643 0.0630 0.0618 0.0606 0.0594 0.0582 0.0571 0.0559
-1.40 0.0808 0.0793 0.0778 0.0764 0.0749 0.0735 0.0721 0.0708 0.0694 0.0681
-1.30 0.0968 0.0951 0.0934 0.0918 0.0901 0.0885 0.0869 0.0853 0.0838 0.0823
-1.20 0.1151 0.1131 0.1112 0.1093 0.1075 0.1056 0.1038 0.1020 0.1003 0.0985
-1.10 0.1357 0.1335 0.1314 0.1292 0.1271 0.1251 0.1230 0.1210 0.1190 0.1170
-1.00 0.1587 0.1562 0.1539 0.1515 0.1492 0.1469 0.1446 0.1423 0.1401 0.1379
-0.90 0.1841 0.1814 0.1788 0.1762 0.1736 0.1711 0.1685 0.1660 0.1635 0.1611
-0.80 0.2119 0.2090 0.2061 0.2033 0.2005 0.1977 0.1949 0.1922 0.1894 0.1867
-0.70 0.2420 0.2389 0.2358 0.2327 0.2296 0.2266 0.2236 0.2206 0.2177 0.2148
-0.60 0.2743 0.2709 0.2676 0.2643 0.2611 0.2578 0.2546 0.2514 0.2483 0.2451
-0.50 0.3085 0.3050 0.3015 0.2981 0.2946 0.2912 0.2877 0.2843 0.2810 0.2776
-0.40 0.3446 0.3409 0.3372 0.3336 0.3300 0.3264 0.3228 0.3192 0.3156 0.3121
-0.30 0.3821 0.3783 0.3745 0.3707 0.3669 0.3632 0.3594 0.3557 0.3520 0.3483
-0.20 0.4207 0.4168 0.4129 0.4090 0.4052 0.4013 0.3974 0.3936 0.3897 0.3859
-0.10 0.4602 0.4562 0.4522 0.4483 0.4443 0.4404 0.4364 0.4325 0.4286 0.4247
0.00 0.5000 0.4960 0.4920 0.4880 0.4840 0.4801 0.4761 0.4721 0.4681 0.4641

You can also draw a picture to go along with your z-score table, so that people remember which area they are looking up:

x <- seq(-4,4,0.1)
y <- dnorm(x)
plot(x,dnorm(x),type="l", col="black", lwd=3)
abline(v=-1,lwd=3,col="blue")
abline(h=0,lwd=3,col="black")
polygon(c(x[1:31],rev(x[1:31])), c(rep(0,31),rev(y[1:31])), col="lightblue")

It looks like this:

z-score-table-icon-small

In the slides, code to produce a giant-tail z-score table is also provided (where the areas are > 50%).

Innovation Tips for Strategic Planning

Image Credit: Doug Buckley of http://hyperactive.to

Image Credit: Doug Buckley of http://hyperactive.to

Over the past 15 years, I’ve helped several organizations with continuous improvement initiatives at the strategic, executive level. There are a lot of themes that keep appearing and reappearing, so the purpose of this post is to call out just a few and provide some insights in how to deal with them!

These come up when you are engaged in strategic planning and when you are planning operations (to ensure that processes and procedures ultimately satisfy strategic goals), and are especially prominent when you’re trying to develop or use Key Performance Indicators (KPIs) and other metrics or analytics.



1) How do you measure innovation? Before you pick metrics, recognize that the answer to this question depends on how you articulate the strategic goals for your innovation outcomes. Do you want to:

  • Keep up with changing technology?
  • Develop a new product/technology?
  • Lead your industry in developing best practices?
  • Pioneer new business models?
  • Improve quality of life for a particular group of people?

All of these will be measured in different ways! And it’s OK to not strategically innovate in one area or another… for example, you might not want to innovate your business model if technology development is your forte. Innovation is one of those things where you really don’t want to be everything to everyone… by design.



2) Do you distinguish between improving productivity and generating impact?

Improving quality (the ability to satisfy stated and implied needs) is good. Improving productivity (that is, what you can produce given the resources that you use) is also good. Reducing defects, reducing waste, and reducing variation (sometimes) are all very good things to do, and to report on.

But who really cares about any improvements at all unless they have impact? It’s always necessary to tie your KPIs, which are often measures of outcomes, to metrics or analytics that can tell the story about why a particular improvement was useful — in the short term, and (hopefully also) in the long term.

You also have to balance productivity and impact. For example, maybe you run an ultra-efficient 24/7 Help Desk. Your effectiveness is exemplary… when someone submits a request, it’s always satisfied within 8 hours. But you discover that no tickets come in between Friday at 5pm and Monday at 8am. So all that time you spend staffing that Help Desk on the weekend? It’s non-value-added time, and could be eliminated to improve your productivity… but won’t influence your impact at all.

We just worked on a project where we had to consciously had to think about how all the following interact… and you should too:

  • Organizational Productivity: did your improvement help increase the capacity or capability for part of your organization? If so, then it could contribute to technical productivity or business productivity.
  • Technical Productivity: did the improvement remove a technical barrier to getting work done, or make it faster or less error-prone?
  • Business Productivity: did the improvement help you get the needs of the business satisfied faster or better?
  • Business Impact: Did the improvements that yielded organizational productivity benefits, technical productivity benefits, or business productivity benefits make a difference at the strategic level? (This answers the “so what” question. So you improved your throughput by 83%… so what? Who really cares, and why does this matter to them? Long-term, why does this awesome thing you did really matter?)
  • Educational/Workforce Development Impact: Were the lessons learned captured, fed back into the organization’s processes to close the loop on learning, or maybe even used to educate people who may become part of your workforce pipeline?

All of the categories above are interrelated. I don’t think you can have a comprehensive, innovation-focused analytics approach unless you address all of these.



3) Do you distinguish between participation and engagement?

Participation means you showed up. Engagement means you got involved, you stayed involved, your mission was advanced, or maybe you used this experience to help society. Too often, I see organizations that want to improve engagement, and all the metrics they select are really good at characterizing participation.

I’m writing a paper on this topic right now, but in the meantime (if you want to get a REALLY good sense of the difference between participation and engagement), read The Participatory Museum by Nina Simon. Yes, it is “about museums” — and yes, I know you’re in business or industry — and YES, this book really will provide you with amazing management insights. So read it!

Analytic Hierarchy Process (AHP) using preferenceFunction in ahp

Yesterday, I wrote about how to use gluc‘s new ahp package on a simple Tom-Dick-Harry one level decision making problem using Analytic Hierarchy Process (AHP). One of the cool things about that package is that in addition to specifying the pairwise comparisons directly using Saaty’s scale (below, from https://kristalaace2014.wordpress.com/2014/05/14/w12_al_vendor-evaluation/)…

saaty-scale

…you can also describe each of the Alternatives in terms of descriptive variables which you can use inside a function to make the pairwise comparisons automatically. This is VERY helpful if you have lots of criteria, subcriteria, or alternatives to evaluate!! For example, I used preferenceFunction to compare 55 alternatives using 6 criteria and 4 subcriteria, and was very easily able to create functions to represent my judgments. This was much easier than manually entering all the comparisons.

This post shows HOW I replaced some of my manual comparisons with automated comparisons using preferenceFunction. (The full YAML file is included at the bottom of this post for you to use if you want to run this example yourself.) First, recall that the YAML file starts with specifying the alternatives that you are trying to choose from (at the bottom level of the decision hierarchy) and some variables that characterize those alternatives. I used the descriptions in the problem statement to come up with some assessments between 1=not great and 10=great:

#########################
# Alternatives Section
# THIS IS FOR The Tom, Dick, & Harry problem at
# https://en.wikipedia.org/wiki/Analytic_hierarchy_process_%E2%80%93_leader_example
#
Alternatives: &alternatives
# 1= not well; 10 = best possible
# Your assessment based on the paragraph descriptions may be different.
  Tom:
    age: 50
    experience: 7
    education: 4
    leadership: 10
  Dick:
    age: 60
    experience: 10
    education: 6
    leadership: 6
  Harry:
    age: 30
    experience: 5
    education: 8
    leadership: 6
#
# End of Alternatives Section
#####################################

Here is a snippet from my original YAML file specifying my AHP problem manually ():

  children:
    Experience:
      preferences:
        - [Tom, Dick, 1/4]
        - [Tom, Harry, 4]
        - [Dick, Harry, 9]
      children: *alternatives
    Education:
      preferences:
        - [Tom, Dick, 3]
        - [Tom, Harry, 1/5]
        - [Dick, Harry, 1/7]
      children: *alternatives

And here is what I changed that snippet to, so that it would do my pairwise comparisons automatically. The functions are written in standard R (fortunately), and each function has access to a1 and a2 (the two alternatives). Recursion is supported which makes this capability particularly useful. I tried to write a function using two of the characteristics in the decision (a1$age and a1$experience) but this didn’t seen to work. I’m not sure whether the package supports it or not. Here are my comparisons rewritten as functions:

  children:
    Experience:
          preferenceFunction: >
            ExperiencePreference <- function(a1, a2) {
              if (a1$experience < a2$experience) return (1/ExperiencePreference(a2, a1))
              ratio <- a1$experience / a2$experience
              if (ratio < 1.05) return (1)
              if (ratio < 1.2) return (2)
              if (ratio < 1.5) return (3)
              if (ratio < 1.8) return (4)
              if (ratio < 2.1) return (5) return (6) } children: *alternatives Education: preferenceFunction: >
            EducPreference <- function(a1, a2) {
              if (a1$education < a2$education) return (1/EducPreference(a2, a1))
              ratio <- a1$education / a2$education
              if (ratio < 1.05) return (1)
              if (ratio < 1.15) return (2)
              if (ratio < 1.25) return (3)
              if (ratio < 1.35) return (4)
              if (ratio < 1.55) return (5)
              return (5)
            }
          children: *alternatives

To run the AHP with functions in R, I used this code (I am including the part that gets the ahp package, in case you have not done that yet). BE CAREFUL and make sure, like in FORTRAN, that you line things up so that the words START in the appropriate columns. For example, the “p” in preferenceFunction MUST be immediately below the 7th character of your criterion’s variable name.

devtools::install_github("gluc/ahp", build_vignettes = TRUE)
install.packages("data.tree")

library(ahp)
library(data.tree)

setwd("C:/AHP/artifacts")
nofxnAhp <- LoadFile("tomdickharry.txt")
Calculate(nofxnAhp)
fxnAhp <- LoadFile("tomdickharry-fxns.txt")
Calculate(fxnAhp)

print(nofxnAhp, "weight")
print(fxnAhp, "weight")

You can see that the weights are approximately the same, indicating that I did a good job at developing functions that represent the reality of how I used the variables attached to the Alternatives to make my pairwise comparisons. The results show that Dick is now the best choice, although there is some inconsistency in our judgments for Experience that we should examine further. (I have not examined this case to see whether rank reversal could be happening).

> print(nofxnAhp, "weight")
                         levelName     weight
1  Choose the Most Suitable Leader 1.00000000
2   ¦--Experience                  0.54756924
3   ¦   ¦--Tom                     0.21716561
4   ¦   ¦--Dick                    0.71706504
5   ¦   °--Harry                   0.06576935
6   ¦--Education                   0.12655528
7   ¦   ¦--Tom                     0.18839410
8   ¦   ¦--Dick                    0.08096123
9   ¦   °--Harry                   0.73064467
10  ¦--Charisma                    0.26994992
11  ¦   ¦--Tom                     0.74286662
12  ¦   ¦--Dick                    0.19388163
13  ¦   °--Harry                   0.06325174
14  °--Age                         0.05592555
15      ¦--Tom                     0.26543334
16      ¦--Dick                    0.67162545
17      °--Harry                   0.06294121

> print(fxnAhp, "weight")
                         levelName     weight
1  Choose the Most Suitable Leader 1.00000000
2   ¦--Experience                  0.54756924
3   ¦   ¦--Tom                     0.25828499
4   ¦   ¦--Dick                    0.63698557
5   ¦   °--Harry                   0.10472943
6   ¦--Education                   0.12655528
7   ¦   ¦--Tom                     0.08273483
8   ¦   ¦--Dick                    0.26059839
9   ¦   °--Harry                   0.65666678
10  ¦--Charisma                    0.26994992
11  ¦   ¦--Tom                     0.74286662
12  ¦   ¦--Dick                    0.19388163
13  ¦   °--Harry                   0.06325174
14  °--Age                         0.05592555
15      ¦--Tom                     0.26543334
16      ¦--Dick                    0.67162545
17      °--Harry                   0.06294121

> ShowTable(fxnAhp)

tomdick-ahp-fxns

Here is the full YAML file for the “with preferenceFunction” case.

#########################
# Alternatives Section
# THIS IS FOR The Tom, Dick, & Harry problem at
# https://en.wikipedia.org/wiki/Analytic_hierarchy_process_%E2%80%93_leader_example
#
Alternatives: &alternatives
# 1= not well; 10 = best possible
# Your assessment based on the paragraph descriptions may be different.
  Tom:
    age: 50
    experience: 7
    education: 4
    leadership: 10
  Dick:
    age: 60
    experience: 10
    education: 6
    leadership: 6
  Harry:
    age: 30
    experience: 5
    education: 8
    leadership: 6
#
# End of Alternatives Section
#####################################
# Goal Section
#
Goal:
# A Goal HAS preferences (within-level comparison) and HAS Children (items in level)
  name: Choose the Most Suitable Leader
  preferences:
    # preferences are defined pairwise
    # 1 means: A is equal to B
    # 9 means: A is highly preferrable to B
    # 1/9 means: B is highly preferrable to A
    - [Experience, Education, 4]
    - [Experience, Charisma, 3]
    - [Experience, Age, 7]
    - [Education, Charisma, 1/3]
    - [Education, Age, 3]
    - [Age, Charisma, 1/5]
  children:
    Experience:
          preferenceFunction: >
            ExperiencePreference <- function(a1, a2) {
              if (a1$experience < a2$experience) return (1/ExperiencePreference(a2, a1))
              ratio <- a1$experience / a2$experience
              if (ratio < 1.05) return (1)
              if (ratio < 1.2) return (2)
              if (ratio < 1.5) return (3)
              if (ratio < 1.8) return (4)
              if (ratio < 2.1) return (5) return (6) } children: *alternatives Education: preferenceFunction: >
            EducPreference <- function(a1, a2) {
              if (a1$education < a2$education) return (1/EducPreference(a2, a1))
              ratio <- a1$education / a2$education
              if (ratio < 1.05) return (1)
              if (ratio < 1.15) return (2)
              if (ratio < 1.25) return (3)
              if (ratio < 1.35) return (4)
              if (ratio < 1.55) return (5)
              return (5)
            }
          children: *alternatives
    Charisma:
      preferences:
        - [Tom, Dick, 5]
        - [Tom, Harry, 9]
        - [Dick, Harry, 4]
      children: *alternatives
    Age:
      preferences:
        - [Tom, Dick, 1/3]
        - [Tom, Harry, 5]
        - [Dick, Harry, 9]
      children: *alternatives
#
# End of Goal Section
#####################################
« Older Entries
